CJ-303JT-SYK 300mm High-Power LED Arrow Traffic Signal Light (Plastic Housing, PC Lens, IP53)

• Anti-Glare Performance
Utilizing a high-transmittance Polycarbonate (PC) lens, the optical distribution is optimized to ensure a uniform and soft signal display. This design effectively minimizes visual fatigue for drivers caused by harsh glare, enhancing overall road safety.

• Global Voltage Adaptability
Supports a wide input range of 85~264VAC, providing resilience against power grid fluctuations and surges. This ensures seamless compatibility with diverse electrical standards across different countries and regions worldwide.

• Operational Continuity
The internal circuitry is precision-engineered to maintain constant brightness during continuous operation. The system is designed to prevent flickering or luminous decay, ensuring the signal remains stable and reliable over long-term activation.

• Energy Efficiency
With a total power consumption rated under 10W, this unit significantly reduces the electrical overhead of municipal traffic systems compared to traditional light sources, contributing to greener urban infrastructure.

• Low Maintenance Costs
The solid-state LED light source generates minimal heat, which effectively slows the aging process of internal materials. This engineering focus aims to extend the hardware replacement cycle and decrease the frequency of onsite maintenance at intersections.

• Protection Rating
Featuring an IP53 protection rating, the enclosure is designed to effectively block dust ingress and resist rainwater splashes, guaranteeing stable performance in outdoor environments.

• High-Strength Materials
The chassis is constructed from a combination of high-grade engineering plastics and PC materials. This provides superior impact resistance, UV stabilization, and excellent electrical insulation, allowing the unit to adapt to extreme outdoor temperatures and harsh weather conditions.

Installation & Compatibility
High-Strength Lightweight Structure: Measuring 1090 × 350 × 135mm with a net weight of approximately 7kg, this unit features a high-quality plastic housing and high-transmittance PC lens. This design maintains structural integrity while effectively reducing overall weight, facilitating easier transportation and on-site installation. It is recommended to use single-arm brackets or double U-bolt structures for fixing to enhance long-term stability.

High-Power Arrow Indicator: Equipped with built-in high-brightness LED light sources (power ≤ 10W), the arrow graphics are clear and sharp. They provide explicit driving direction guidance even at long distances or under strong light environments, making them particularly suitable for complex lane diversion scenarios.

Strong System Compatibility: Supports integration with standard traffic signal control systems, allowing for independent control of single-direction arrow signals to meet refined traffic management requirements.

Convenient Maintenance Structure: The lamp set utilizes a split-body design where the light source components and power modules are laid out independently. This facilitates rapid inspection and replacement, thereby reducing maintenance time.

Applications
Multi-Lane Diversion Intersections: Suitable for intersections with distinct lane diversions, providing clear arrow signals to define vehicle driving directions and improve transit efficiency.

Dedicated Left/Right Turn Lanes: Used in dedicated turning lanes to reinforce directional instructions and reduce navigation errors and traffic conflicts.

Expressways & Elevated Ramps: Provides clear directional guidance in urban expressway or elevated bridge ramp areas, helping drivers anticipate their travel paths in advance.

Internal Road Systems for Parks: Ideal for internal roads within large industrial or logistics parks to standardize vehicle flow and improve overall traffic organization efficiency.

This series of products supports B2B bulk purchasing. The minimum order quantity and delivery cycle vary depending on the specific configuration. We offer OEM branding services and can provide customized lamp body colors or housing options based on project requirements.
Sunshades, backplates, mounting brackets, and pole accessories are available as separate options.
For technical inquiries, quote requests, or project specification support, please contact our sales team and provide information such as the project location, required quantity, installation method, and applicable local technical standards. Samples can be provided for evaluation and testing prior to bulk purchasing.
